DYS GoTeck GS-1723MG Digital Servo, Full Metal Gear
₹899Incl. GST
SKU DYS-GS-1723MG
Brand: DYSMade in India: NoWeight: 21 gTorque: 4.2 kg-cm
Ships within 3–4 business days — quality-checked in Gurugram before dispatch
Free standard shipping on orders of ₹999 and above. Pan India delivery from Gurugram, Haryana.
Questions about this part? Ask us on WhatsApp
Buying in bulk? Ask for a better price on WhatsApp or by email.
- 100% genuine parts
- GST invoice with every order
- Secure payments — cards, UPI & net banking via Razorpay
- 7-day returns on wrong or damaged items
Product details
The GoTeck GS-1723MG from DYS is a 21g digital servo with full metal gears, rated 4.2 kg-cm at 6V. Its mini-size 28 x 13.2 mm case and metal gear train suit control surfaces on mid-size RC planes and gliders, helicopter duties, RC car steering and robotics where plastic gears wear out.
Key features
- Full metal gear train for durability under load
- 3.8 kg-cm at 4.8V, 4.2 kg-cm at 6V
- 0.14 s/60° at 4.8V, 0.12 s/60° at 6V
- Digital control with FET drive, 5 µs dead band and 333Hz support
- 180° travel, with overload protection that cuts current when the output is stalled
- Long 300mm 28AWG lead
Specifications
- Operating voltage: 4.8-6V
- Torque: 3.8 kg-cm at 4.8V, 4.2 kg-cm at 6V
- Speed: 0.14 s/60° at 4.8V, 0.12 s/60° at 6V
- Rotation: 180°
- Weight: 21g
- Dimensions: 28 x 13.2 x 29.6 mm
- Neutral / frame rate: 1520 µs / 333Hz
- Dead band: 5 µs
- Case: Plastic
- Lead: 300mm, 28AWG (black -, red +, white signal)
Power it from the receiver rail or a 4.8-6V BEC; a 2S LiPo connected directly reaches 8.4V and exceeds its rating.
| Brand | DYS |
|---|---|
| Made in India | No |
| Weight | 21 g |
| Torque | 4.2 kg-cm |
| Gear Material | Metal |
| Signal Type | Digital |
| Servo Size | Mini |
| Rotation Range | 180 deg |
