Dupont 2.54mm 5-Pin Connector, Male or Female

₹39Incl. GST

SKU GEN-DUPONT-254-5P-M

Connector: Male

Made in India: NoBrand: GenericConnector Type: DupontPin Count: 5
Dispatched within 2–3 business days — quality-checked in Gurugram

Free standard shipping on orders of ₹999 and above. Pan India delivery from Gurugram, Haryana.

Questions about this part? Ask us on WhatsApp

Buying in bulk? Ask for a better price on WhatsApp or by email.

Product details

5-pin Dupont connector with the standard 2.54 mm (0.1 in) pitch, available as the male plug or the female socket. Use it to make custom signal leads for 2.54 mm pin headers on receivers, servo rails, Arduino and Raspberry Pi boards and other bench or ground electronics.

Key features

  • Five contacts in one housing for a multi-wire signal run, such as a UART lead with power.
  • Male and female versions mate with each other, so a pair makes an inline lead you can disconnect.
  • Rated up to 1 A and 250 V, for 22–28 AWG wire.
  • Operating range of −25 to +85 °C.

Specifications

  • Pitch: 2.54 mm
  • Contacts: 5
  • Current rating: 1 A
  • Voltage rating: 250 V
  • Wire size: 22–28 AWG
  • Operating temperature: −25 to +85 °C
  • Versions: Male, Female

Choose the version that matches the other side: a female socket plugs onto male header pins, while a male plug goes into a female header or socket. Keep it to signal wiring, as 1 A is far too little for battery or motor power.
