DJI Goggles Integra

The DJI Goggles Integra streamlines the digital FPV experience for pilots flying the DJI O3+ video transmission system. By merging the headband and battery into a single unified piece, these goggles eliminate dangling power cables and standalone battery packs. Engineered for cinematic flying, long-range cruising, and high-performance freestyle, they deliver sharp visual feedback through dual 1080p Micro-OLED screens. The Integra is fully compatible with the DJI O3 Air Unit, DJI Avata, and previous-generation Caddx Vista or RunCam Link digital systems.

Key features

• Integrated 2450mAh battery headband for balanced weight distribution and cable-free operation.
• High-definition Micro-OLED displays pushing 1080p resolution at a 100Hz refresh rate.
• DJI O3+ video transmission providing up to 50Mbps video bitrate and latency as low as 30ms.
• Built-in GPS to meet broadcast requirements for Remote ID compliance.
• Foldable directional antennas for compact storage and transport.

Specifications

• Weight: 410 g (including battery)
• Displays: 2x Micro-OLED (1920x1080)
• Screen brightness: up to 700 nits
• Field of view (FOV): 44°
• Refresh rate: Up to 100 Hz
• Interpupillary distance (IPD): 56-72 mm
• Battery: Built-in 2450mAh 2S Li-ion (approx. 2 hours runtime)
• Operating frequency: 2.400-2.4835 GHz, 5.725-5.850 GHz (auto-switching)
• Storage: microSD, up to 512 GB
• Not compatible with: DJI Avata 2

Unlike the DJI Goggles 2, the Integra uses physical diopter lenses rather than built-in adjustable dials. A set of standard corrective lenses is included for pilots requiring vision correction.
