AXL Everfly 35000mAh 6S LiPo Battery

The AXL Everfly 35000mAh 6S is a 22.2 V LiPo for endurance UAVs, inspection platforms, ground rovers and robotics on 6S power, packing the capacity of several paralleled smaller batteries into one 2.5 kg brick. Axl Drone makes the Everfly range in India.

Key features

• 777 Wh per pack: 35,000mAh in a 6S1P layout, 25.2 V at full charge.
• 5C continuous and burst: suited to low, steady draw such as long hover, mapping runs or rover drive.
• AS150 anti-spark power connector and a 7-pin JST-XH balance lead.
• Charges at up to 0.5C (17.5 A), at least two hours per full charge.
• Made in India by Axl Drone.

Specifications

• Capacity: 35,000 mAh
• Configuration: 6S1P LiPo
• Nominal voltage: 22.2 V (25.2 V full)
• Energy: 777 Wh
• Continuous discharge: 5C
• Burst discharge: 5C
• Max charge rate: 0.5C (17.5 A)
• Power connector: AS150
• Balance connector: JST-XH, 7-pin
• Dimensions: 190 × 87 × 66 mm
• Weight: 2.5 kg

Most 6S ESCs and power modules accept this pack, but fit a matching AS150 lead and make sure the frame can carry 2.5 kg of battery. At 777 Wh it cannot travel in airline baggage, so move it to site by road.
