Amass XT30 Female Connector — Black (5 Pack)

This pack of five genuine Amass XT30 female connectors is moulded in black high-temperature nylon. Featuring gold-plated socket contacts, female XT30s are the standard choice for terminating 2S to 4S micro drone batteries, or for fabricating custom charging leads and parallel boards.

Key features

• Genuine Amass manufacturing ensures precise fitment and consistently low contact resistance.
• Gold-plated brass sockets rated for 15A continuous and up to 30A burst current.
• High-temperature nylon housing resists melting or deforming during soldering.
• Half-open solder cups easily accommodate 16AWG to 20AWG silicone wire.

Specifications

• Connector type: XT30 Female
• Current rating: 15A continuous, 30A burst
• Recommended wire: 16AWG to 20AWG
• Material: Gold-plated brass contacts, Nylon/PA housing
• Colour: Black
• Quantity: 5 pieces

In standard FPV wiring conventions, female connectors are installed on the battery side (with the socket contacts shielded to prevent accidental shorts), while male connectors are soldered to the drone's ESC or power lead.
