Amass XT30 Connector Black (1 Pair)

The genuine Amass XT30 connector pair is an essential component for custom micro FPV builds, whoops, and sub-250g drones requiring a reliable, high-current power link in a compact footprint. Moulded from high-temperature nylon with solid gold-plated spring pins, these connectors offer a secure, low-resistance fit that easily outperforms standard JST-RCY pigtails. The black housing provides a sleek, uniform look for stealthy custom wire harnesses.

Key features

• Genuine Amass manufacturing ensures consistent mating cycles and a tight fit to prevent mid-flight disconnects.
• Gold-plated 2mm contacts handle up to 15A continuous and 30A burst current without overheating.
• Half-open solder cups easily accept and grip silicone power wire up to 16AWG.
• Lightweight profile makes it the standard choice for 2S to 4S micro quads and toothpick builds.

Specifications

• Brand: Amass
• Connector type: XT30 (1x Male, 1x Female)
• Colour: Black
• Continuous current rating: 15A
• Peak current rating: 30A
• Contact size: 2mm
• Recommended wire gauge: 16-18AWG
• Material: Gold-plated brass contacts, Nylon/PA housing

Pro tip: Always plug a spare mating connector into the side you are soldering to act as a heat sink. This keeps the pins perfectly aligned and prevents the plastic housing from warping under prolonged contact with your soldering iron.
