RadioMaster WT01 Wireless Trainer Module Adapter — TX16S

The RadioMaster WT01 Wireless Trainer Module eliminates the need for a physical tether cable between master and student transmitters. Plugging directly into the trainer port of your RadioMaster TX16S, it acts as a dedicated wireless receiver that binds to the student radio, allowing instructors to seamlessly take back control during FPV or fixed-wing flight training.

Key features

• Creates a stable wireless student-master link, freeing both pilots from a restrictive trainer cord.
• Built-in 250mAh battery powers the module for up to 240 minutes without draining the master radio.
• Features multi-protocol support, allowing the student radio to bind via D8, D16, or SFHSS.
• Recharges quickly via a standard USB-C port.
• Includes the necessary adapter cabling for direct compatibility with the RadioMaster TX16S.

Specifications

• Supported protocols: FrSky D8, D16, Futaba SFHSS
• Battery: Built-in 250mAh
• Operating time: Approx. 240 minutes
• Charging interface: USB-C
• Weight: 20g

To operate, plug the WT01 into the trainer port of the master TX16S, configure the master radio's trainer profile, and bind the student transmitter directly to the WT01 module.
