DOGCOM 6S 5200mAh 120C LiPo Battery (XT90)

The DOGCOM 6S 5200mAh LiPo is built for cinelifters and other heavy-lift FPV rigs that run 6-cell power on an XT90 discharge lead. The 5200mAh capacity suits larger builds where runtime matters, while the 120C discharge rating targets setups that draw heavy current without the battery becoming the bottleneck.

Key features

• 6S1P configuration for 22.2V nominal voltage on standard 6-cell heavy-lift builds.
• 5200mAh capacity for longer flight sessions on larger frames.
• 120C continuous discharge rating for demanding throttle bursts and high-load use.
• XT90 discharge connector for high-current draw, with a separate JST-XHR balance/charge plug.
• Metal plate casing adds impact protection over a standard soft pack.
• BIS-certified to Indian safety standards.

At 158 x 48 x 45mm this pack suits mid-size to large heavy-lift frames with a battery bay sized for a full 6S pack; check tray clearance against these dimensions before ordering for a tight-fitting build.

Specifications

• Cell count: 6S (22.2V nominal)
• Capacity: 5200mAh
• Discharge rating: 120C
• Connector: XT90 (discharge), JST-XHR (charge)
• Dimensions: 158 x 48 x 45mm
• Weight: about 790 g
