EMAX ECO Micro 1106 CW Brushless Motor
₹949Incl. GST
SKU EMAX-ECO-1106-4500KV-CW
KV: 4500KV
Stator Size: 1106KV: 6000 KV, 4500 KVProp Mount: 1.5mmShaft: 1.5mm
Free shipping. Pan India delivery from Gurugram, Haryana.
Ships within 3–4 business days — quality-checked in Gurugram before dispatch
Questions about this part? Ask us on WhatsApp- 100% genuine parts
- GST invoice with every order
- Secure payments — cards, UPI & net banking via Razorpay
- 7-day returns on wrong or damaged items
Product details
The EMAX ECO Micro 1106 is a lightweight 1106 brushless motor for 2S-3S micro and whoop FPV builds, offered in a 6000KV winding for 2S and a 4500KV winding for 2-3S, where fast throttle response and top-end speed on small props matter most.
Key features
- 9N12P winding configuration for smooth, linear power delivery
- Weighs just 6.7g without wire, among the lightest motors in its class
- 9x9mm mounting pattern fits the most common micro quad frames
- 1.5mm prop adapter shaft with a 2mm bearing shaft and steel construction
- 100mm 26AWG silicone lead wire for flexible, heat-resistant wiring
- CW rotation for the clockwise position in a mixed motor set
Specifications
- Stator size: 1106
- KV: 6000KV (2S) or 4500KV (2-3S)
- Max thrust: 214 g on 2S (6000KV) / 280 g on 3S (4500KV)
- Weight: 6.7g (without wire)
- Dimensions: 19.9 x 14.2mm
- Recommended propeller: 2-3 inch
- Motor mount: 9x9mm
Best suited to 2S micro racing and freestyle whoops running 2-3 inch propellers; match it with correct-rotation partner motors on the same build.
| Stator Size | 1106 |
|---|---|
| Stator Diameter | 11mm |
| Stator Height | 6mm |
| KV | 6000 KV, 4500 KV |
| Prop Mount | 1.5mm |
| Shaft | 1.5mm |
| Motor Mount | 9x9mm |
| Input Voltage | 2–3S |
| Weight | 6.7 g |
| Brand | EMAX |
| Made in India | No |
