BetaFPV 4S Whoop XT30 Cable Pigtail with Capacitor (1pc)
SKU BETAFPV-4S-WHOOP-PIGTAIL-XT30
Free shipping. Pan India delivery from Gurugram, Haryana.
Ships within 3–4 business days — quality-checked in Gurugram before dispatch
Questions about this part? Ask us on WhatsApp- 100% genuine parts
- GST invoice with every order
- Secure payments — cards, UPI & net banking via Razorpay
- 7-day returns on wrong or damaged items
Product details
BetaFPV XT30 power pigtail for 4S whoops, with a 25V 220µF capacitor built into the lead to absorb voltage spikes before they reach the flight controller and ESC. It is the replacement battery lead for the BetaFPV F4 V2 4S FC and F4 2-4S AIO FC used on Beta85X-class 4S whoops.
Key features
- Inline capacitor protects the ESC from the voltage spikes that motors throw back onto the power rail
- Amass XT30 plug on heatproof, soft silicone wire that stays flexible in a tight whoop frame
- Short overall length keeps the lead tidy on a 4S whoop
- Supplied as a single cable
Specifications
- Connector: XT30
- Wire: 18AWG silicone
- Length: 65mm including the plug
- Capacitor: 25V, 220µF, ±20%
- Battery support: 2–4S LiPo
- Weight: 3.2g
- Compatible boards: BetaFPV F4 V2 4S FC, F4 2-4S AIO FC
Solder the pigtail to the board's battery pads observing polarity, keep the capacitor clear of the props and duct edges, and re-check the joints after a hard crash. The 25V rating leaves comfortable headroom over a fully charged 4S pack at 16.8V.
| Battery Connector | XT-30 |
|---|---|
| Made in India | No |
| Brand | BetaFPV |
| Wire Gauge | 18AWG |
| Cell Count | 2–4S |
