APC 11x5.5MR-B4 Multirotor Propeller Bundle, Grey

A set of four APC multirotor propellers in 11x5.5 inch: two 11x5.5MR standard-rotation props and two 11x5.5MRP reverse-rotation props, enough for one quadcopter. APC designed the MR series for multirotors. The 11-inch diameter and 5.5-inch pitch suit larger camera and payload quads on low-to-mid KV motors.

Key features

• 2 x 11x5.5MR (standard rotation) and 2 x 11x5.5MRP (reverse rotation)
• 1/4 inch shaft bore that takes APC LPAR06E adapter rings (1/8 in, 4mm, 5mm, 6mm and 5/16 in) for other motor shafts
• Hub 0.65 inch across and 0.35 inch thick
• APC part number LP11055MR-B4

Specifications

• Diameter: 11 in (279.4 mm)
• Pitch: 5.5 in (139.7 mm)
• Blades: 2 per propeller
• Quantity: 4 (2 standard + 2 reverse rotation)
• Hub diameter: 0.65 in (16.5 mm)
• Hub thickness: 0.35 in (8.9 mm)
• Shaft bore: 1/4 in (6.35 mm)
• Weight: 0.60 oz (about 17 g) per propeller
• Colour: grey
• Part number: LP11055MR-B4

Fit the MR props on the motors that spin in the standard direction and the MRP props on the reverse-rotation motors. A prop on the wrong motor pushes air upwards and the quad flips at take-off. On camera rigs, balance each prop before its first flight to keep vibration out of the footage.
