Molicel P28A 3S2P 5600mAh Li-Ion Battery Pack

A 3S2P lithium-ion pack assembled to order from genuine Molicel INR-18650-P28A cells: 2 cells in parallel per group, 3 groups in series, 6 cells in total. It delivers 5600mAh at 10.8V nominal (60.5Wh) with 70A of continuous discharge — the energy density of Li-ion at a current rating that suits 3" to 5" long-range FPV builds, small fixed-wing aircraft and portable electronics.

Specifications

• Configuration: 3S2P (6 × Molicel P28A 18650)
• Capacity: 5600mAh · 60.5Wh
• Voltage: 10.8V nominal · 12.6V fully charged · 7.5V cutoff
• Continuous discharge: 70A (35A per cell)
• Main connector: your choice of XT-60 / XT90-AS — pick it above
• Balance lead fitted for standard balance chargers
• Approx. weight: 331 g

Build

Every pack is built in Gurugram from matched, capacity-tested cells with spot-welded nickel busbars, silicone main leads and a heat-shrink wrap, then load-tested before dispatch. Packs are assembled after payment and dispatch within 3–4 business days. Need a different connector, wire length or layout? Ask us on WhatsApp before ordering.

Charging and care

Charge in Li-Ion mode at 4.20V per cell (never LiHV) at up to 5.6A (1C). Do not discharge below 2.5V per cell; land at around 3.3V per cell for the longest cycle life. Store at 3.6–3.7V per cell.
